ZEN Module Grain Size Analysis Hardware License Key

ZEN Module Grain Size Analysis Hardware License Key Module for grain size determination
- Creation and administration of workflows (job templates) for customer specific requirements
- Separation into supervisor and user mode
- Options of acquisition: Single shots, tiles acquisition, load file from directory, load file from archive Three measurement methods:
- Planimetric method: Automatic reconstruction of grain borders (single grains measurement and determination of the grain size distribution)
- Intercept method: Semiautomatic measurement with chord pattern
- Compare method: Manual with comparative diagrams (wall charts)
- Measurement according to following standards: DIN EN ISO 643:2012; ASTM E 112-13 Plate I
- IV; ASTM E 1382-97; GB/T 6394 2002
- Archiving of all measurements and generated data
- Display of results in data lists, in the graphics plane of the image and for the Planimetric method as histogram
- Creation of reports in Microsoft Word and export in docx, pdf and xps
- Creation and free customizing of all report templates with Microsoft Word Add-In
- Creation and free customizing of all input forms with new form designer
- New loop function in job mode for higher efficiency in repetitive procedures
- Newly designed result view for better monitoring of results
