ZEN Module Comparative Diagrams Hardware License Key

ZEN Module Comparative Diagrams Hardware License Key Module for comparing micrographs with comparative charts (Wall Charts)
- Separation into supervisor and user mode
- Creation and administration of workflows (job templates) for customer specific requirements
- Archiving of all measurements and generated data
- Two options for Image sources: life mode, stored data
- Comparison with one, two, four or eight Comparative Diagrams in one view
- Overlay possibility of image and chart for direct comparison
- Optional storage of images and data tables for documentation purposes in the archive
- Creation of reports in Microsoft Word and Export in docx, pdf and xps
- Creation and free customizing of all report templates with Microsoft Word Add-In
- Creation and free customizing of all input forms with new form designer
- New loop function in job mode for higher efficiency in repetitive procedures
- Newly designed Result View for better monitoring of results
- Provided standards:
- Grains: DIN EN ISO 643:2012; ASTM E 112-13 Plate I
- IV; GB/T 6394 2002
- Non-metallic inclusion (NMI): ISO 4967:2013; GB-10561; EN 10247:2007, ASTM E 45:2013; DIN 50602:1987
- Graphite: EN ISO 945-1: 2008 + Cor. 1: 2010
- Chart Series Creator: Functionality for generation of customer specific charts Additional information:
- The license of the Comparative Diagrams (Wall Chart Images) from the standards is included in the product.
- The particular standard license has not to be present on the customer's site any longer.
