ZEN 2 core Package Hardware License Key with Axiocam 305 color (D)

ZEN 2 core Package Hardware License Key with Axiocam 305 color (D) consisting of the camera Axiocam 305 color and the ZEN 2 core basic software plus the ZEN Module Image Analysis Camera specification: Microscopy camera incl. Driver software 64bit, USB 3.0 PCIe x1 interface, USB 3.0 cable 3 m and IR barrier filter Hoya C5000 (coated) Number of Pixels: 2464 (H) x 2056 (V) = 5.07 Mega pixel color Sensor type: SONY IMX264 Exmor Pregius Global Shutter CMOS Pixel size: 3.45 μm x 3.45 μm Chip size: 8.5 mm x 7.1 mm, equivalent to 2/3" (diagonal 11.1 mm) Spectral range: With IR barrier filter app. 400 nm to 720 nm Full Well Capacity: Approx. 10,500 e Selectable Resolution: H x V Binning Factor 2464 x 2056 1x1 Basic Resolution 1232 x 1028 2x2 816 x 684 3x3 608 x 514 4x4 480 x 410 5x5 H x V Subsampling Factor 2464 x 2056 1x1 Basic Resolution 1232 x 1028 2x2 Live frame rates (depending on hardware and software configuration): H x V Frame Rate@1ms 2464 x 2056 36 fps 1232 x 1028 88 fps (2x2 Subsampling) Frame rates for time series recording (depending on computer hardware and software configuration) H x V (ROI) Frame Rate 2464 x 2056 36 fps 2048 x 2048 36 fps 1920 x 1080 67 fps 1024 x 1024 70 fps 512 x 512 136 fps 256 x 256 255 fps 128 x 128 456 fps Readout of Sensor Sub-Regions ("ROI"): Adjustable Digitization: 8 and 12 Bit / Pixel Dynamic Range: Typical> 4800 : 1 (>73 dB) at typ. 2.2 e readout noise Dark current: <(><<)> 1.0 e/p/s @ 25°C Integration Time: 0.1 ms to to 4 s Cooling: Temperature stable @ 25°C for ambient temperatures between 18°C and 30°C Status-LED for Camera: color coded operation status, dimmable, Interface (camera): USB 3.0 interface Optional operation with USB 2.0 connection at reduced frame rate Optical Interface: C-Mount Thread depth for objectives: max. 5 mm Size / Weight: approx. App. 10.8 cm x 7.8 cm x 4.3 cm (2.3"x3.2"x1.7") / 580 g Housing: blue anodized aluminum, with cooling fins on top, 1/4" photo thread for tripod mount Registration: CE Power Supply: Max. 4W, power supply provided by USB 3.0 bus for camera electronics Environmental conditions: 5° … +35° Celsius, max 80% relative air humidity, not condensing, free air circulation required Supported Operating Systems: Windows 10 x64 Enterprise, Windows 7 SP1 x64 Professional/Ultimate
