ZEN 2 core Package Hardware License Key with Axiocam 105 color (D)

ZEN 2 core Package Hardware License Key with Axiocam 105 color (D) consisting of the camera Axiocam 105 color and the ZEN 2 core basic software plus the ZEN Module Image Analysis Camera specification: Microscopy camera with driver software 64bit, USB 3.0 PCIe x1 interface, USB 3.0 connection cable 3.0 m, SATA power cable and Molex power cable Sensor: Aptina CMOS color sensor Basic resolution: 2560 (H) x 1920 (V) = 5.0 Mega pixels color Pixel size: 2.2 µm x 2.2 µm Chip size: 5.70 mm x 4.28 mm, equivalent to 1/2.5" (diagonal 7.1 mm) Live frame rates (depending on hardware and software configuration): H x V Binning Factor Frame Rate@1ms 2560 x 1920 1 15 1280 x 960 2 37 640 x 480 4 47 Frame rates for time series recording (depending on hardware and software configuration): H x V Binning Factor Frame Rate@1ms 2560 x 1920 1 8 1280 x 960 2 16 640 x 480 4 19 Readout of Sensor Sub- Regions ("ROI"): Adjustable Digitization: 3 x 8 Bit / Pixel Integration Time: 100 µs up to 2 s Interface (camera): USB 3.0 Micro-B Interface (PC / board): USB 3.0 Standard A Spectral range: Approx. 400 nm
- 650 nm, IR filter Read-out mode: Progressive Optical Interface: C-Mount (adapter 0.5x recommended) Size / Weight: approx. 2.9 cm x 2.9 cm x 4.76 cm / 50 g Housing: Aluminum, Magnesium, Stainless Steel Registration: CE, FCC Class B, RoHS Power Supply: via USB 3.0 interface, max. 1.7 W (5 V, 0.34 A) Environmental conditions: 0° ... +50° Celsius, max. 80% relative air humidity, no condensation, free air circulation required Supported operating systems: Windows 7 x64 Prof./Ultimate SP1
