AxioVision SE64 Materials Core Package with Axiocam 503 color (D)

AxioVision SE64 Materials Core Package with Axiocam 503 color (D) consisting of the camera Axiocam 503 color, USB 3.0 PCIe x1 interface, dual USB 3.0/USB 2.0 cable 3 m and the following software. The AxioVision basic program plus the functionality of the AxioVision modules:
- Extended Focus
- Panorama
- Interactive Measurement adapted to Materials Microscopy
- Online Measurement
- AutoMeasure
- Asset Archive Camera specification:
- Number of Pixels: 1936 (H) x 1460 (V) = 2.8 Mega pixels color
- Pixel size: 4.54 µm x 4.54 µm
- Chip size: 8.8 mm x 6.6 mm, equivalent to 2/3" (11 mm diagonal)
- Spectral range: With IR barrier filter app. 400 nm to 720 nm
- Max. Full Well Capacity: Approx. 15.000 e
- Selectable Resolution: H x V Binning Factor 1936 x 1460 1x1 Basic Resolution 968 x 728 2x2 Monochrome 640 x 484 3x3 Color/Monochrome 480 x 364 4x4 Monochrome 384 x 292 5x5 Color/Monochrome
- Selectable color interpolation quality levels: "High Speed Color" for fastest processing speed or "High Quality Color" for best interpolation results High Quality Black and White conversion mode.
- Live frame rates (depending on hardware and software configuration): Exp. Time 10ms, color enhancement off, 39 Mhz pixel clock, Quadport Readout H x V Binning Factor Frame Rate, 1936 x 1460 1 38 640 x 484 3 76 384 x 292 5 93
- Frame rates for time series recording Continuous Mode with 39 Mhz pixel clock and QuadPort Readout (depending on computer hardware and software configuration) H x V Binning Factor Frame Rate 1936 x 1460 1 38 968 x 728 2 61 640 x 484 3 76 480 x 364 4 87 384 x 292 5 93
- Timelapse recording with "Burst Mode"-function
- Readout of Sensor Sub-Regions ("ROI"): Adjustable
- Digitization: 14 Bit / 39 MHz or 13 MHz pixel clock
- Dynamic Range: Typical>2500 : 1 (>68 dB) at typ. <6.5 e readout noise
- Dark current: ca. 0.06 e/p/s
- Integration Time: 1 ms to 60 s
- Cooling: One stage Peltier cooling, regulated to 18°C sensor temperature,
- Additional digital dark current compensation, Calibrated color space optimization,
- Eight pre-loadable sets of imaging parameters for speed optimized multi modal image acquisition, acquisition Time Stamp with image data,
- Status-LED for Camera: color coded operation status, dimmable,
- Status-LED for Trigger: color coded trigger status, dimmable,
- I/O Control signals: galvanic isolated I/O signals for exposure time, readout time, trigger ready, (i.e. for controlling external mechanical shutters), one trigger input for exposure control, 5V auxiliary voltage, GND
- Interface: USB 3.0, 240 MBytes/s, 3 m double-USB cable with USB 3.0/USB 2.0,
- Optional operation with USB 2.0 connection at reduced frame rate,
- Optional operation without cooling for use at short exposure times with reduced power consumption,
- Optical Interface: C-Mount, Teflon coated thread
- Thread depth for objectives: max. 5 mm
- Max. file size per image: app. 17 MB at 1936 x 1460 pixels at 3 x 14 bit/pixel
- Size / Weight: app. 10.8 cm x 7.8 cm x 4.3 cm (2.3"x3.2"x1.7") / 500 g
- Housing: blue anodized aluminum, with cooling fins, 1/4" photo thread for tripod mount
- Registration: CE,
- Power Supply: power supply provided by USB 3.0 bus for camera electronics and USB 2.0 for Peltier-cooling,
- Power consumption: 7W (5V, 1.4A)
- Environmental conditions: 5° ... +35° Celsius, max 80% relative air humidity, not condensing, free air circulation required
- Supported operating systems: Windows 7 x64 Prof./Ultimate SP1
