AxioVision SE64 Materials Core Package with Axiocam 105 color (D)

Description:AxioVision SE64 Materials Core Package with Axiocam 105 color (D) consisting of the camera Axiocam 105 color and the following software. The AxioVision basic program plus the functionality of the AxioVision modules:
- Extended Focus
- Panorama
- Interactive Measurement adapted to Materials Microscopy
- Online Measurement
- AutoMeasure
- Asset Archive Camera specification:
- Microscopy Camera Axiocam 105 color with USB 3.0 PCIe x1 interface, USB 3.0 connection cable 3.0 m, SATA power cable and Molex power cable
- Basic resolution: 2560 (H) x 1920 (V) = 5.0 Megapixel
- Pixel size: 2.2 µm x 2.2 µm
- Chip size: 5.70 mm x 4.28 mm, equivalent to 1/2.5" (diagonal 7.1 mm)
- Live frame rates (depending on hardware and software configuration): H x V Binning Factor Frame Rate@1ms 2560 x 1920 1 15 1280 x 960 2 37 640 x 480 4 47
- Frame rates for time series recording (depending on hardware and software configuration): H x V Binning Factor Frame Rate@1ms 2560 x 1920 1 8 1280 x 960 2 16 640 x 480 4 19
- Readout of Sensor Sub-Regions ("ROI"): Adjustable
- Digitization: 3 x 8 Bit / Pixel
- Integration Time: 100 µs up to 2 s
- Interface (camera): USB 3.0 Micro-B
- Interface (PC / board): USB 3.0 Standard A
- Optical Interface: C-Mount (adapter 0.5x recommended)
- Size / Weight: approx. 2.9 cm x 2.9 cm x 4.76 cm / 50 g
- Housing: Aluminum, Magnesium, Stainless Steel
- Registration: CE, FCC Class B, RoHS
- Power Supply: via USB 3.0 interface, max. 1.7 W (5 V, 0.34 A)
- Environmental conditions: 0° ... +50° Celsius, max. 80% relative air humidity, no condensation, free air circulation required
- Supported operating systems: Windows 7 x64 Ultimate SP1
