AxioVision 4 Module Topography

AxioVision 4 Module Topography Module to create height maps from acquired z-stack images or interactively by acquiring images from different focus positions.
- Height information is derived from the focus position of the motorized focus drive.
- Height information is generated in a topographic image. Display of in-focus areas in a texture map Display of the height information of the in-focus areas in a height image.
- Generation of isometric 3D images: Projection Texture projection Wiremesh Surface
- Measurement of roughness parameters according to EN ISO 4287 Ra, Rq, Rku: Rsk, Rv, Rp, Rt
- Generation of data tables containing roughness parameters
- Flooded display og Height map and Projection image
