AxioVision 4 Module NMI Module for automatic measurement of the content of Non Metallic Inclusions (NMI) like sulphides, oxides and titanium nitrides in rolled steels.
- Separation into administration and user mode
- Creation and administration of test specifications for adjusting to customer specific requirements
- Data base supported archive of all test specifications and measuring objects (SQL data base)
- Image sources: MosaiX, saved images, images opened in AxioVision
- Analysis according to following standards: EN 10247:2007; DIN 50602_1985; ASTM E 45_2005; ISO 4967:1998; JIS G 0555:2005
- Image analysis defined in commander skripts
- Display of the results in charts, data lists and statistical evaluation
- Worst Inclusion Gallery
- Automatic repositioning of the stage for refinding inclusions
- Interactive correction of the measurement
- Archiving of all data tables (raw data, statistics and classification) for documentation purposes
- Creation and free modification of report templates
- Reports can be saved in internal format and be exported into pdf
- Optional storage of images in original size or zoomed down, as well with annotations
- Separation in acquisition and analysing workstation
