AxioVision 4 Module LM-EM Correlative Microscopy Shuttle & Find Module for image recording and correlation on light and electron microscopes.
- Image acquisition on light microscopes (LM) and electron microscopes (EM) with saving capability in ZVI format
- Import of the major SEM parameters into the AxioVision image
- Live window of the SEM image to be scanned with the option of interrupting and continuing the scan
- Loading of SEM TIF images with the major parameters stored in them
- Loading of SEM TIF tiles and the major parameters stored in them for the creation of an unstitched MosaiX image (stitching additionally requires the MosaiX AxioVision module
- Possibility of using tiles for navigation and for the creation of LM or SEM images
- Semi-automatic calibration of the CorrMic specimen holder and possibility of manual calibration of holders and specimen with any type of marking
- Navigation on LM or SEM on the basis of calibrated images:
- Movement to the same position and, on SEM, additional setting of the same magnification
- Fine calibration for enhanced positioning accuracy
- Definition and setting of up to 100 ROIs and points
- Display of the current SEM / LM position in the loaded image
- Saving and loading of the settings for image creation
- Manual superimposition of LM and SEM images and creation of overlay images as new images
