AxioVision 4 Module Correlative Particle Analyzer (CAPA)

AxioVision 4 Module Correlative Particle Analyzer (CAPA) In combination with the MosaiX module and the SmartPI EM software, the AxioVision Correlative Particle Analyzer Module serves for detailed material characterization with in-depth information, which delivers combined results from light and electron microscope analysis.
- module for Correlative Particle Analysis (LM/EM) (already includes functionality of the modules Particle Analyzer Projects and Asset Archive)
- semiautomatic calibration for the definition of a reference coordinate system
- import of particle data tables from the current or an optional Particle Analyzer Archive Project. The data transfer may be carried out via an external data carrier or a PC network made up of LM and EM computers
- selection of the desired reflective particles based on n-sized particles or an optional particle size range
- fully automatic EDX analysis of the previously selected particles with the generation of an analysis report including the combined resultsfrom light and electron microscope analysis in accordance with ISO 16232and VDA 19
- easy particle relocalization on the EM, the particles selected following the LM analysis and analyzed using EM/EDX may be relocated on demand by one button
- optional fine calibration for enhanced positioning accuracy
- various operating modes for result display
- parallel particle analysis on LM and EM
- data synchronization of correlative projects: at the touch of one button, all data tables, images and spectrums generated from the current EM analysis are saved in the Particle Analyzer archive; placed in a project folder which contains all data from the joint LM and EM analysis
- image capture on the EM with storage capability in ZVI image format
- import of the major SEM parameters into the AxioVision image
